Every cabinet in the One Source 2026 catalog has a nomenclature code. Once you know the pattern, you can read a cabinet list the way you read a plan, and catch problems before an order goes to production.
How is a One Source cabinet code built?
Most codes follow the same order:
- Cabinet type (wall, base, tall, vanity and so on)
- Doors (1D, 2D)
- Drawers (TD for top drawer, BD for bottom drawer)
- Interior (S for shelves, ROT for rollouts, PART for partitions)
What do the cabinet type prefixes mean?
| Prefix | Cabinet |
|---|---|
| W | Wall |
| WDD | Wall, doors down |
| GW | Glass wall |
| VWL / WHF | Vertical wall lift / wall high fold |
| WDC / WBC / WC90 | Wall diagonal corner / wall blind corner / wall corner 90 |
| B | Base, door and drawer |
| BFH | Base, full-height door |
| SB | Sink base |
| DB | Drawer base |
| FLB / FLSB | Floating base / floating sink base |
| OB | Open base |
| LS | Lazy susan (base corner 90) |
| TBFH | Tall, full-height door |
| TA | Tall appliance |
| VT / VSD | Vanity top / vanity combo |
| FLS | Floating shelf |
What do the suffixes mean?
- 1D, 2D: number of doors
- 1TD, 2TD: number of top drawers
- 1BD, 2BD: number of bottom drawers
- 0S to 4S: number of adjustable shelves
- 1ROT to 4ROT: number of rollouts
- 1PART to 3PART: number of partitions
- FF: false front, common on sink bases
- PD: pencil drawer
- L / R: left or right hand, used on corners and fillers
Can you walk through a few examples?
- W-2D-3S: wall cabinet, two doors, three shelves.
- B-2D-1TD-2ROT: base cabinet, two doors, one top drawer, two rollouts.
- SB-2D-1FF: sink base, two doors, one false front.
- TBFH-2D-3ROT: tall full-height pantry, two doors, three rollouts.
- WC90L-0S: wall corner 90, left hand, no shelves.
What about fillers, panels and trim?
Fillers, end panels, crown and toe kick have their own codes, such as BDF (base doweled filler), WEP and BEP (wall and base end panels), CF (flat crown) and TK (toe kick). We cover those in a separate guide to fillers, end panels and scribe.
Where do I find size ranges for each code?
The specification pages at the back of the 2026 catalog PDF list minimum and maximum width, height and depth for every code. Your One Source designer confirms final sizes before production. Every cabinet uses the same construction, listed on our specifications page.
Bidding a project in Mesa, Phoenix or Colorado Springs? See our contractor program or read The Contractor’s Guide to Ordering Custom Cabinets.
Frequently asked questions
What does W-1D-2S mean?
W-1D-2S is a One Source wall cabinet with one door and two adjustable shelves.
What does ROT mean on a cabinet code?
ROT means rollout. B-1D-1TD-2ROT is a base cabinet with one door, one top drawer and two rollouts.
What is the difference between W and WDD?
W is a standard wall cabinet. WDD is a wall cabinet with doors down, where the door extends below the box.
Where are cabinet size ranges listed?
The specification pages of the One Source 2026 catalog list minimum and maximum width, height and depth for every code. Your designer confirms final sizes.
Specifications and finish counts are from the One Source Cabinets 2026 Product Catalog (October 2026 revision).
